HDZero Race V2

  • Sale


  • Regular price $124.99

Tax included. Shipping calculated at checkout.
Order in 0H, 44M, 42 Seconds (before 3pm AEST) for same day despatch.


Description



The HDZero Race VTX is a digital HD 720p 60fps video transmitter capable of delivering up to 200mw on 5.8GHz. It works with the Shark Byte RX5.1 goggle module to transmit video, and with a remote controller to wirelessly control the parameters for the transmitter and camera.



Specifications





Model:

HDZero Race V2

SKU

HDZ3140

Frequency:

5.8G

Resolution Default:

1280*720@60fps

RF power

25mw/200mw

RF Connector:

Secured U.FL

Interface:

4 lane MIPI CSI YUV422

Video Connector:

20 Position 0.30mm Pitch

Size:

34mm x 34mm x 6mm

Weight:

5.9g

Power

410mA@12V

power input

7V-26V(2S-6S)

Mounting

20mm x 20mm M4 with rubber grommets



Includes



HDZero Race V2 VTX * 1;

Power/ Uart Cables * 5;

Zip ties * 4;

Rubber Grommet (M4 to M3) * 8

u.FL Antenna Retention Screws * 4/Nut * 4/Plate * 1
